With integrated impact absorber, fall indicator clamp and constant pressure spring. End fitting both ends of the system, both ends constant spring-assisted cable tension (1 set = 2 pcs)
For straight run cable systems up to 30 metres long with integrated impact absorber, fall indicator clamp and constant pressure spring. End fitting both ends of the system, both ends constant spring-assisted cable tension (1 set = 2 pcs)
Universal intermediate cable point with 1 mounting point for roof and cladding systems, moves through 180°, can be accessed from both ends, for special applications can be fixed in 5 steps, can be passed over
Art. No.
Description
48910400
Intermediate cable point GZH
INTERMEDIATE CABLE POINT ZH-X
not passable
Material:
Stainless steel
Application:
Not suitable for SDW 1 and SDW 2. Cannot be passed over
Art. No.
Description
48910500
Intermediate cable point GZH X
INTERMEDIATE CABLE POINT
LONG ZH-40
Material:
Stainless steel
Application:
Universal intermediate cable point with 1 mounting point for roof, cladding and overhead systems flexibly bendable up to 40°, moves through 180°, can be accessed from both ends, for special applications, 5 stage fixing, can be passed over
Art. No.
Description
48991100
Intermediate cable point long GZH 40
Corner EH-45
EH 45
Material:
Stainless steel
Application:
45° corner with 1 mounting point, for an inside or outside corner, as well as for overhead systems.
Art. No.
Description
48911300
Corner GEH 45°
Corner EH-90
EH 90
Material:
Stainless steel
Application:
90° corner with 1 mounting point, for an inside or outside corner, as well as for overhead systems.
Art. No.
Description
48911200
Corner GEH 90°
Flex corner
Material:
Stainless steel
Application:
Universal cable pulley with 1 mounting point, for all angles up to 180°, cannot be passed over
Art. No.
Description
48911600
Cable pulley
STAINLESS STEEL CABLE
Material:
Stainless steel (V4A)
Diameters:
8 mm (7 x 7 wires)
Breaking strength:
36 kN
Art. No.
Description
47901011
Stainless steel cable Green
DATA TAG
GREENLINE 795 C
To identify the cable system 1 data tag per end fitting set
